Spindle Moulders

IWM offer a full range of Spindle Moulders for Sale. Please ask for further details of the extensive range as this is only one of many machines in the range, from Manual Rise & Fall to Fully Automatic Spindle Moulders with a host of Options to match your exact requirements.

Example Non Tilt, Casadei F23 Spindle Moulder and Casadei F25 Spindle Moulder with 45 Degrees +/- Tilting

Spindle Moulders, with Infeed & Outfeed Tables, Sliding Tables, Power Feeds etc.


Description of one of Many Spindle Moulders we can supply Model F255A Casadei Spindle Moulder

The electrospindle controlled by inverter, the spindle tiltable ± 45,5° and the wide range of options available, make the F 255A spindle moulder suitable for the most demanding users.

Advantages

Flexibility: The numerical control can control all the axes installed on the machine. Electronic programming ensures rapid machine set-ups eliminating the need of test runs. With a few keystrokes stored programs can be recalled or new machining quotas inserted. The wide range of options available, including the HSK version, allow any type of machining.

Sturdiness: Sturdy steel machine structure. Ribbed cast iron worktable which guarantees no vibrations. The electrospindle tilts over two heavy duty cast iron trunnions.

If you would like to find out more information please contact Ian anytime (24/7 response) either by email ibrown@iwmachines.co.uk or call +44 (0)7944 108747.

For more information please click an icons below
Technical Data
  • Worktable dimensions 1200 x 780 mm
  • Spindle diameter, your choice 30-35-40-50 mm
  • 1 ¼
  • Spindle rotation speeds rpm 900 ÷ 12.000
  • Spindle tilt± 45,5°
  • Max. tool diameter when profiling 250 mm
  • Max. tool diameter when tenoning 300 mm
  • Motor power (S6-40%) 7,5 kW / 10 Hp
